Product Parameter:
|
Model |
ZTDH12 |
|
Operating weight(Kg ) |
12200 |
|
Ground pressure(KPA) |
51 |
|
Min. Turning Radius(mm) |
3900 |
|
Grade ability(°) |
30 |
|
Max.draw bar pull(KN) |
115 |
|
Min.ground clearance(mm) |
380 |
|
Width of standard Track Shoes(mm) |
500 |
|
Track centers(mm) |
1860 |
|
Length of Track On Ground(mm) |
2525 |
|
Engine |
|
|
Engine Mode |
6A3LR20/0920 |
|
Power/Speed (kw/r/min) |
92/2000 |
|
Emission standard |
China Stage III |
|
Min.Fuel consumption(G/KW.h) |
≤246 |
|
Engine max torque(N.m) |
526 |
|
Fuel type |
Diesel |
|
Travel system |
|
|
Carrier Rollers (Each side) |
2 |
|
Track Rollers (Each side) |
6 |
|
Drive system |
Hydrostatic Transmission |
|
Steering clutch |
Wet,Hydraulic steering |
|
Steering Brake |
Wet ,Float,Belt ,Hydraulic braking |
|
Suspension Method |
Semi-rigid suspension |
|
Speed gear |
|
|
Forward gear(km/h) |
F:0-10 |
|
Reverse gear(km/h) |
R:0-10 |
|
Bulldozer shovel |
|
|
Blade Type |
Straight |
|
Bulldozer height |
1040 |
|
Bulldozer width(mm) |
3250 |
|
Blade max lifting height(mm) |
894 |
|
Blade max digging depth(mm) |
400 |
|
Scarifier Type |
Three-teeth scarifier (Optional) |
|
Blade lifting height(mm) |
480 |
|
Blade digging depth(mm) |
380 |
