Diesel Generator Set Technical Parameter:
Model | MY250 | Steady-state voltage adjustment rate (%) | ≤±1 |
Output Power | 250KW | Voltage fluctuation rate | ≤±0.5 |
Power Factor | COSΦ=0.8 (Lag) | Transient voltage adjustment rate (%) | ＋20～－15 |
Output Voltage | 400V/230V | Voltage stability time (s) | ≤1 |
Output Current | 450A | Steady state frequency adjustment rate (%) | ≤±1 |
Rated frequency | 50Hz | Frequency fluctuation rate (%) | ≤±0.5 |
Rated speed | 1500rpm | Transient frequency adjustment rate (%): | +10 ~ -7 |
Fuel Grade | 0 # light diesel | Frequency stabilization time (S) | ≤3 |
Overall dimensions | 3150*1180*1700 (L*W*H mm) | Fuel consumption (100% load) | 205g/kw.h |
Weight (kg) | 3100 | Noise (LP7m): | 95dB (A) |
Diesel Engine Technical Parameter:
Brand / Origin | DCEC CUMMINS | cooling method | Water cooled |
Diesel Engine Model | 6LTAA9.5-G1 | Fuel supply method | Direct injection |
Diesel Engine Rated Power | 290 KW | Diesel engine reserve power | 320 KW |
Displacement | 8.9 L | Fuel System | 7100 pump/GAC Electronic governor |
Number of cylinders | 6 | Adjustment speed Method | Electronic |
Bore / stroke | 114×145mm | Intake method | Turbocharged |
compression ratio | 16.6：1 | Overload capacity | 110% |
Start mode | DC24V electric start | Speed | 1500rpm |
Lubricant capacity: | 27.6 L | Coolant capacity: | 11.1L |
Generator Technical Parameters:
Motor brand | Kangwo Holdings / Xingnuo | Protection class | IP23 |
Motor model | KOF-XN250 | Wiring method | three-phase four-wire, Y-type connection |
Rated Power | 250 KW | Regulation | AVR (Automatic Voltage Regulator) |
Rated Volatage | 400V/230V | Output frequency | 50Hz |
Insulation class | H class | Power Factor | COSΦ=0.8 (Lag) |
FAQ:
Q: What is the power output of the generator set?
A: 250 KW
Q: What is the brand of the engine?
A: DCEC CUMMINS
Q: What is the output voltage of the generator set?
A: 400V/230V
