Product Specifications:
|
MODEL |
|
4TON |
|
Rated Load |
Kg |
4000 |
|
Lifting Height |
mm |
3000-6000 |
|
Vehicle Weight |
kg |
5250 |
|
Ground Clearance |
mm |
135 |
|
Speed Full Load |
Km/h |
20 |
|
Tyre Front /Rear |
|
250-15-16PR/7.00-12-12PR |
|
Mast Tilting Angle Front /Rear |
|
6°/12° |
|
Wheel Base |
mm |
2000 |
|
Min Turning Radius |
mm |
2690 |
|
Engine Model |
|
XINCHAI4D32G31-029 |
|
Engine Power |
Kw/rpm |
36.8/2500 |
|
Dimensions |
|
2893*1225*090 |
|
Fuel Type |
|
Diesel |
Features:
1.Simple appearance, generous and beautiful, strict environmental protection design
2.Wide vision door frame design broadens the driver's vision
3.Reliable LCD digital special instrument, friendly man-machine page, easy for the driver to accurately control the vehicle state
4.The new steering wheel adjustment structure, which improves the operation comfort and adjustment reliability
5.The design of the high-top large-diameter air intake system can keep the engine away from dust, effectively exert the engine performance and prolong the life.
6.Optional casting steering axle, low maintenance cost later.
Production Details:
FAQ:
Q: How long is the product warranty period?
A: Half a year from the goods leaving the factory.
Q: What is the Capacity?
A: 4 Ton
