Stabilized Soil Mixing Machine Product Features:
1. Modular building block design, easy to install and transfer, and can be combined according to user's needs.
2. The main frame adopts a rectangular tube design, and the one-line arrangement or the L-shaped arrangement can be switched at will.
3. Excellent mixing performance using APMM double-shaft mixer, high strength, large capacity, no wear. Highly wear-resistant alloy blades, multi-blade mixing, thoroughly and quickly, for optimum mixing quality.
4. The weight of the aggregate is the weight of the double roller, the measurement is stable, the fluctuation is small, and the precision is high.
5. Powder weighing is the structure of the reduction scale. The feeding amount can be precisely controlled according to the change of the weight of the hopper; Self-dropping feeding method, the weighing monitoring time can reach more than 90%; the special feeder can provide a very uniform flow and ensure the linear feeding required for feedback control. (Also available with auger scale structure)
6. Online feedback control the first-stage volume measurement adopts frequency conversion speed control, and the second-stage weighing measurement adopts belt scale. The weighing signal is transmitted to the weighing processor to directly control the frequency converter to adjust the feeding amount. Fully automatic online feedback control for superior metering accuracy.
7. Weighing control Weighing + PLC + computer control can be operated manually and automatically. Proportioning ratio setting, the adjustment is precise and convenient, and the whole machine is equipped with a safety alarm emergency stop system.
Stabilized Soil Mixing Machine Product Parameter (Specification):
|
Description |
|
MYP500 |
|
Production capacity |
t/h |
500 |
|
Main motor power |
kw |
90 |
|
Aggregate hopper capacity |
m3 |
10 |
|
Powder bin |
t |
50, 80 |
|
Mixed material storage silo |
m3 |
8 |
|
Measurement method |
/ | Electronic weighing measurement |
|
Aggregate hopper loading height |
m |
3.68 |
|
Discharge height |
m |
3.86 |
Stabilized Soil Mixing Machine Production Details:
FAQ:
Q: How long is the product warranty period?
A: One year or 1200 hours after leaving the factory, which comes first.
Q: What is the production capacity?
A: 500t/h.
