| Engine | Cummins 6LT9.3 |
| Rated Power | 168KW |
| Net Power | 152 KWkW(204 hp/207 ps)@2,000 rpm |
| Operating Weight | 16,800 kg |
| Standard Bucket Size | 3.0m³ |
| Standard Breakout Force | 168kN |
| Standard Dump Clearance | 3,037 mm |
|
ENGINE |
|
|
Emission Regulation |
Tier 2 / Stage II |
|
Manufacturer |
Cummins |
|
Model |
6LT9.3 |
|
Rated Power |
162 kW (217 hp / 220 ps) @ 2,000 rpm |
|
Net Power |
152 kW (204 hp / 207 ps) @ 2,000 rpm |
|
Peak Torque |
980 N · m @ 1,200-1400 rpm |
|
Displacement |
9.3 L |
|
Number of Cylinders |
6 |
|
Aspiration |
Turbocharged |
|
TRANSMISSION |
|
|
Transmission Type |
Planetary, power shift |
|
Torque Converter |
Double stage, four elements |
|
Maximum Travel Speed, fwd |
36.3 km/h |
|
Maximum Travel Speed, rev |
14.5 km/h |
|
Number of Speeds, fwd |
2 |
|
Number of Speeds, rev |
1 |
|
AXLES |
|
|
Differential Front Type |
Conventional |
|
Differential Rear Type |
Conventional |
|
Axle Oscillation |
±10° |
|
STEERING |
|
|
Steering Configuration |
Articulated |
|
Steering Relief Pressure |
17.2 Mpa |
|
BRAKES |
|
|
Service Brake Type |
Caliper discs brake |
|
Service Brake Actuation |
Air over hydraulic |
|
Parking Brake Actuation |
Drum |
|
Parking Brake Actuation |
Manua air control |
|
HYDRAULIC SYSTEM |
|
|
Main Pump Type |
Gear |
|
Main Relief Pressure |
20.7 MPa |
|
Raise Time |
5.6 s |
|
Dump Time |
1.5 s |
|
Float Down Time |
3.0 s |
|
Fastest Total Cycle Time |
10.1 s |
|
LOADER ARM PERFORMANCE WITH STANDARD BUCKET 3.0 m3 |
|
|
Tipping Load - Straight (ISO 14397-1:2007) |
12,500 kg |
|
Tipping Load - Full Turn (ISO 14397-1:2007) |
11,100 kg |
|
Bucket Breakout Force |
168 kN |
|
A Maximum Hinge Pin Height |
4,114 mm |
|
B Dump Clearance at Full Height Discharge |
3,037 mm |
|
C Dump Reach at Full Height Discharge |
1,169 mm |
|
D Maximum Digging Depth, Bucket Level |
50 mm |
|
S1 Bucket Rollback at Ground Level |
42.7° |
|
S2 Bucket Rollback at Carry |
48° |
|
S3 Bucket Rollback at Maximum Height |
62.6° |
|
S4 Maximum Dump Angle at Full Height |
46° |
|
BUCKET PERFORMANCE |
|
|
Reference Bucket |
2.7-4.0 m³ |
|
DIMENSIONS |
|
|
E Ground Clearance |
431 mm |
|
G Wheelbase |
3,250 mm |
|
H Cab Height |
3,500 mm |
|
J Wheel Tread |
2,150 mm |
|
K Width Over Tires |
2,750 mm |
|
L Length with Bucket Down |
7,923 mm |
|
M Turn Angle, Either Side |
38° |
|
P Rear Angle of Departure |
30° |
|
R1 Turning Radius, Outside of Tire |
6,086 mm |
|
R2 Turning Radius, Bucket Carry |
6,779 mm |
|
W Width Over Bucket |
2,970 mm |
|
TIRES |
|
|
Tire Size |
23.5-25 PR16 L-3 TT |
|
OPERATING WEIGHTS |
|
|
Operating Weight |
16,800 kg |
|
SERVICE CAPACITY |
|
|
Fuel Tank |
300 L |
|
Engine Oil |
26 L |
|
Cooling System |
40 L |
|
Hydraulic Reservoir |
232 L |
|
Transmission and Torque Converter |
45 L |
|
Axles, Each |
33 L |
