Industrial Diesel Generator

Weichai Group(industrial-diesel-generator) is the only enterprise in China with the four major business platforms of the whole car, the power assembly, the luxury yacht and auto parts. It is an international company cross-region, inter-bank operations, and the molecular prior is Europe, North America, Southeast Asia and other regions. Weichai has established a modern "national-level technology center" and domestic first-class product labore, in Austria, built a European R & D center, and multiple projects are listed in the National "863 Program". The advantage of Weichai engine is that the fuel consumption is low, high reliable, long life, high torture.

Send Inquiry

Description

Industrial Diesel Generator Set Technical Parameter:

Model	MY500	Steady-state voltage adjustment rate (%)	≤±1
Output Power	500KW	Voltage fluctuation rate	≤±0.5
Power Factor	COSΦ=0.8 (Lag)	Transient voltage adjustment rate (%)	＋20～－15
Output Voltage	400V/230V	Voltage stability time (s)	≤1
Output Current	900A	Steady state frequency adjustment rate (%)	≤±1
Rated frequency	50Hz	Frequency fluctuation rate (%)	≤±0.5
Rated speed	1500rpm	Transient frequency adjustment rate (%)	+10 ~ -7
Fuel Grade	0 # light diesel	Frequency stabilization time (S)	≤3
Overall dimensions	405015401920 (LWH mm)	Fuel consumption (100% load)	210g/kw.h
Weight	5200kg	Noise (LP7M)	95dB (A)

Industrial Diesel Engine Technical Parameter:

Brand / Origin	Weichai, Shandong	cooling method	Water cooled
Diesel Engine Model	6M33D572E200	Fuel supply method	Direct injection
Diesel Engine Rated Power	520KW	Diesel engine reserve power	572 KW
Displacement	19.6L	Oil Capacity	60.5L
Number of cylinders	6	Adjustment speed Method	Electronic
Bore / stroke	150×185mm	Intake method	Turbocharged
compression ratio	15：1	Overload capacity	110%
Start mode	DC24V electric start	Speed	1500rpm
Coolant capacity	41.63L

Industrial Generator Technical Parameters:

Origin	Kangwo Holdings	Protection class	IP23
Motor model	KOF-XN500	Wiring method	three-phase four-wire, Y-type connection
Rated Power	500 KW	Regulation	AVR (Automatic Voltage Regulator)
Rated Voltage	400V/230V	Output frequency	50Hz
Insulation class	H class	Power Factor	COSΦ=0.8 (Lag)
