Type |
Unit |
SC210 |
|
Working mass |
T |
21.3 |
|
Bucket capacity(SAE) |
m3 |
0.9-1.1 |
|
Engine model |
6BTAA5.9 |
|
|
Power |
kw/r/min |
133/2200 |
|
Volume of fuel tank |
L |
350 |
|
Travel speed (High/Low) |
km/h |
5.8/3.2 |
|
Swing speed |
r/min |
10.7 |
|
Grade ability |
° |
35 |
|
Digging force of bucket |
KN |
147.9 |
|
Digging force of stick |
KN |
107.3 |
|
Specific pressure of ground contact |
KPA |
45.3 |
|
Traction |
220 |
|
|
Maximum flow |
L/min |
280*2(223*2) |
|
Working pressure |
MPA |
34.3 |
|
Volume of hydraulic fluid tank |
L |
230 |
|
A-Overall length |
mm |
9390 |
|
B-Overall Width |
mm |
2780 |
|
C-Overall height(tape of boom) |
mm |
3140 |
|
D-Overall height(tape of cab) |
mm |
3090 |
|
E-Gap from counterweight to ground |
mm |
1080 |
|
F-Min ground clearance |
mm |
470 |
|
G-Tail swing radius |
mm |
2800 |
|
H-Length of track on ground |
mm |
3260 |
|
J-Track length |
mm |
4070 |
|
K-Gauge |
mm |
2180 |
|
L-Width of track |
mm |
2780 |
|
M-Width of track shoe |
mm |
600 |
|
N-Width of turning table |
mm |
2700 |
|
O-Max. digging height |
mm |
9270 |
|
P-Max. dumping height |
mm |
6600 |
|
Q-Max. digging depth |
mm |
6525 |
|
T-Max. digging distance |
mm |
9820 |
|
U-Max. digging distance at plane |
mm |
9630 |
|
Min. swing radius |
mm |
3800 |
|
Max height at min swing radius |
mm |
7640 |
|
Distance from center of swing to rear end |
mm |
2870 |
|
Y-Thickness of track grouses |
mm |
26 |
|
Height of counterweight |
mm |
2120 |
|
Ground Contact length (in transportation) |
mm |
4970 |
|
Length of stick |
mm |
2900 |
|
Length of boom |
mm |
5700 |
