Product Introduction:
Asphalt mixing equipment is a complete set of equipment for mass production of asphalt concrete. It is the necessary equipment for highway, high-grade highway, municipal highway, airport and port construction.
Product Features:
• Aggregate grading adopts belt feeding, frequency conversion speed regulation, convenient and accurate adjustment;
• High efficiency vibrating screen, frame structure vibration is small;
• All electronic load cells, accurate and reliable;
• New double horizontal shaft forced mixer, mixing quickly and evenly, stable quality;
• Building block modular design, compact structure, convenient transportation, quick installation;
• Optimized design of drying roller blade layout, high thermal efficiency;
• Choose imported or domestic light and heavy oil burners;
• Computer management and control system, with hierarchical rate storage, report printing, fault monitoring and alarm functions.
Product Parameter (Specification):
Model | AD1000 | AD1200 | |
Production capacity | t/h | 60-80 | 72-96 |
Mixing ability | kg/batch | 1000 | 1200 |
Drying drum size | m | Φ1.6*6.5 | Φ1.6*6.5 |
Vibrating screen | 4 layers 4 size | 4 layers 4 size | |
Aggregate measurement accuracy | % | ±0.3 | |
Powder measurement accuracy | % | ±0.25 | |
Asphalt measurement accuracy | % | ±0.15 | |
Noise at the operator's ear | db (A) | 70 | |
Dust emission concentration | mg/Nm3 | ≤100 Bag filter * | |
Aggregate hopper capacity | m3 | 8x4 | 8x4 |
Optional: Wet dust collector.
FAQ:
Q: How long is the product warranty period?
A: One year or 1200 hours after leaving the factory, which comes first.
Q: What is the production capacity?
A: 60-80t/h
